Standard Features
- Syncs to SMPTE, EBU and IRIG-B time codes
- Complete flexibility in daylight saving time and time zone configurations
- Front indicator light provides synchronization status
- Microprocessor-controlled stepper motor with sweeping second hand for quiet operation
- Battery-backed real time clock chip in case of loss of syncronization or power

Time Code Inputs
- SMPTE (30/25/25 fps - non-drop frame only) to Leitch Date Encoding Standard
- IRIG-B pulse width coded (unmodulated) DC, IEEE 1344 standard
- IRIG-B(1) 1 kHz Amplitude Modulated, IEEE 1344 standard

Configuration
- Configure devices through supplied WinDiscovery software
- Configuration is saved to nonvolatile memory and survives power losses

Power
- 90-265 VAC 50/60 Hz
- IEC AC power connector and cord

Holdover Accuracy
- With loss of power, device reverts to an internal battery-backed real-time clock chip with accuracy of ± 1min/year or < 165ms per day

Connectors
- BNC female
- Optional twisted pair to BNC adapter available
- IEC 320 AC input
- USB port for configuration

Physical
- Size: 45w x 6.35h cm
- Weight: 3.13kg
- Black powder-coated steel chassis
- PETG lens
- Wall mount bracket provided

Operating Parameters
- Temperature: 0 to 60°C
- Humidity: Up to 90% (non-condensing)

Optional
- Face plate ilumination
- Stainless steel case

Warranty
- 5-year limited parts and labor warranty

Compliance
- FCC, CE Marked, ROHS, ANSI
