Features
- 1 or 2 inputs: 1 input driving 12 outputs or 2 inputs each driving 6 outputs
- Output banks are selectable AC or DC coupled
- Universal worldwide AC power
- Dual isolated output banks
- Steel chassis in rust resistant black powder coat
- Adjustable gain control
- Green power LED on front panel

Physical
- Size: 43w x 4.31h x 11.5d cm
- Weight: 0.5 kg

Power
- International IEC 90-240 VAC, 50/60 Hz - Power consumption: < 15 watts

Operating Parameters
- Temperature: 0 to 60°C
- Humidity: Up to 90% (non-condensing)

Inputs - 1
- RF
Frequency: 0 Hz – 20 MHz
Level: 1 V rms [15 dBm max]
Impedance: 50 .
Isolation: A to B >85 dB
- Pulse /DC IRIG Time Code
Frequency: 1PPS to 10 MPPS
Level: 0-7V p-p
Duty Cycle: 0 to 100%
Impedance: 50 .
- AM IRIG Time Code
Frequency: 1 PPS to 10 MPPS
Level: 0-6 V p-p
Modulation: Frequency Up to 1 MHz
Code Format: Any IRIG format, IEEE 1344, NASA 36, 2137, XR3
Impedance: 50

Outputs - 16
- RF
Frequency: 0 Hz – 20 MHz
Level: 1 V rms [15 dBm max]
Gain: 0 dB to 12 dB trimable
Harmoic: <-40 dBc
Non-harmonic: <-80 dBc
Non-harmonic: <-80 dBc
Load Impedance: 50 .
- Pulse /DC IRIG Time Code
Duty Cycle: 0 to 100%
Rise Time: < 20 ns
Fall Time: < 20 ns
Skew: < +2 ns
Load Impedance: 50 .
- AM IRIG Time Code
Frequency: 1 PPS to 10 MPPS
Modulation: Frequency Up to 1 MHz
Code Format: Any IRIG format, IEEE 1344, NASA 36, 2137, XR3
Load Impedance: 50

Warranty
- 5-year limited parts and labor warranty

Compliance
- FCC, CE Marked, ROHS, ANSI
